The opening of the exhibition Making Art Concrete: Works from Argentina and Brazil in the Colección Patricia Phelps de Cisneros marks an important moment in the years-long research project that preceded it.

Beginning in 2015, my colleagues and I at the Getty Conservation Institute had the unique opportunity to conduct the first-ever technical examination of 46 Concrete artworks from Argentina and Brazil on loan from the Colección Patricia Phelps de Cisneros. The exhibition and accompanying catalog present technical aspects of a selection of these works, from information on the many unusual support constructions to the artists’ painting materials and techniques.

Making the Invisible Visible

Among the non-invasive examination techniques we employed for understanding how each work was made was the use of ultraviolet light (UV), also known as black light, which incites a colored fluorescence, or “glow,” in certain materials and which allows us to see aspects of a work that remain invisible under regular illumination. Ultraviolet radiation was first discovered in 1801 by the German chemist Johann Wilhelm Ritter(1) and has found especially wide use in the medical profession. Since around 1925 it has been commercially available to the conservation profession.(2)

For works of art, the UV examination process involves positioning an ultraviolet lamp in front of the surface of a work in a dark room. A few artists’ materials, depending on their chemical structure and condition, will briefly absorb ultraviolet radiation and then reflect some of this energy in visible light wavelengths (i.e., fluoresce). Most substances actually do not fluoresce, but many of the compounds that do fluoresce are organic and appear in paintings, such as aged linseed oil and natural resin varnishes.

The Fluorescence of Age

Generally speaking, the older the oil paint or varnish, the stronger its greenish fluorescence under UV. This characteristic green fluorescence can be observed in Concreto 37, a work by Judith Lauand from 1956, for which the artist chose an alkyd-based paint, found in many Brazilian Concrete works from this period (images above).

Alkyds are a form of polyester resin combined with drying oil, in this case with the addition of pine resin. Areas in which the white background paint was applied more densely appear as roughly circular forms under UV. The strong fluorescence witnessed in this work can be attributed to the presence of aged drying oil and resin.

A number of pigments are also known to fluoresce, such as genuine madder lake, which is found in Old Master paintings, and zinc white, which was widely used by Concrete artists in Latin America (for example in Concreto 37). But since binders and pigments are almost always encountered in a matrix and often in layers, rather than separately, it can be difficult to correctly assess the intensity and color of their fluorescence or absence thereof. For example, earth pigments in linseed oil, the most common binder in tube oil paints, have an inhibiting effect on the development of fluorescence and yellowing, whereas white lead and cobalt blue have a stimulating effect.(3) Apart from zinc white, the other main white pigment identified in the works in our study is titanium white, which neither inhibits nor enhances fluorescence, while zinc white by itself fluoresces pinkish or yellowish-green, depending on the exact UV light source and the kinds of impurities and extenders present.

The Other End of the Spectrum

The ultraviolet region of the electromagnetic spectrum lies just past the blue end of the visible spectrum, at 400nm, which means that ultraviolet radiation has shorter wavelengths than visible light, which is in the region of 400 to 700nm. At the other end of the electromagnetic spectrum is infrared, a region that extends from 700nm to 1mm. Since some pigments become transparent in the infrared region, but other materials do not—for example, carbon-based underdrawings— pentimenti (compositional changes) and faded or obscured inscriptions can often be detected.

At left, visible light image of Alternado 2 shows red and gray lines on a beige background. At right, infrared image of the lower left corner of the painting shows a gray image in which a signature is visible, though it was painted over.

Left: Alternado 2, 1957, Hermelindo Fiaminghi (Brazilian, 1920–2004). Alkyd on hardboard, 61.9 × 62 × 4.5 cm (framed). New York, The Museum of Modern Art. Promised gift of Patricia Phelps de Cisneros through the Latin American and Caribbean Fund in honor of Catalina Cisneros-Santiago. Right: Detail of bottom left corner of Alternado 2 in infrared light: earlier signature visible in lower left corner, now covered with white paint.

Infrared reflectography (IRR), another important non-invasive examination technique in our study, helped us reveal for example Hermelindo Fiaminghi’s earlier signature in the bottom left corner of his painting Alternado 2 from 1957. Fiaminghi at one point concealed this first pencil signature with white paint, before adding a second, still-visible signature in the top right corner.(4)

Informed Interpretation

Due to the complexity of a painting structure, none of these examination techniques alone allows unequivocal identification of a binder, pigment, or varnish, nor a comprehensive understanding of the paint layer sequences in any given work. Hence every approach is combined with close visual examination under a microscope, pigment and binder analysis, paint cross sections, as well as information from other sources such as artists’ interviews and archival photographs.

There is also the misconception, even among some art professionals, that scientific analysis is a straightforward process where a paint sample is simply inserted into an instrument (such as a Fourier-transform Infrared Spectrometer) and the resulting spectrum tells the scientist what the material is. In reality, analysis usually identifies several components present in a paint sample, consisting of a mixture of binder, pigment, and other additives, which requires the informed interpretation by conservation scientists and conservators.

Retouching The Past

The same complexity applies to the interpretation of UV images because the multitude of layers and paint components interact and interfere with each other as they age. In addition, conservation treatments such as varnish removals/applications or retouchings can also leave traces that are visible under ultraviolet illumination. Retouchings and overpaint often appear as black areas, since the binding media have not yet aged as much as the original materials and since the conservation materials used differ from the ones found in the original.

At left, image of Concreto 61 shows black lines in a cross pattern on a beige ground. At right, under UV light the painting's background looks green with small black splotches.

Left: Concreto 61, 1957, Judith Lauand (Brazilian, 1922–). Alkyd on hardboard, 60.2 × 60.2 × 5 cm. New York, The Museum of Modern Art. Promised gift of Patricia Phelps de Cisneros through the Latin American and Caribbean Fund in honor of Robert Menschel & Janet Wallach. Right: Concreto 61 under UV illumination. © 2017 Artists Rights Society (ARS), New York / AUTVIS, Sao Paulo

The ultraviolet image of Concreto 61, a work by Judith Lauand from 1957, shows such small black areas of retouching throughout the surface, some of them clustered around the edges where more paint abrasion is likely to occur.

These small interventions by a conservator are nothing unusual for a painting more than fifty years old. The overall greenish fluorescence of the surface (and examination with a microscope) indicates the presence of an aged varnish layer, which seems to have been applied on top of an earlier campaign of retouchings, and as a result, they appear grey, rather than deep black. They are located primarily along the top edge and in the bottom right corner and probably contain titanium white, which also appears grey under UV.

At an unknown date, Objeto ativo (amarelo) by Willys de Castro from 1959–60 sustained some damage in the right half of the painting.

At top, image of Object ativo (amarelo) under visible light is a yellow rectangle with a thin line of blue at the far left. In the middle of the blue line is a small yellow square. At the far right of the painting, a small blue square mirrors the placement of the small yellow square. At bottom is an image of the painting under UV light. The yellow of the painting looks green and brushstrokes are visible. The blue is a lighter, more translucent blue than in the visible light image.

Top: Objeto ativo (amarelo), 1959–60, Willys de Castro (Brazilian, 1926–88). Oil on canvas on hardboard, 35 × 70 × 1.8 cm. New York, The Museum of Modern Art. Promised gift of Patricia Phelps de Cisneros through the Latin American and Caribbean Fund in honor of Lord and Lady Foster. Bottom: Objeto ativo (amarelo) under UV illumination.

The two areas, one an oblong vertical shape toward the left and the other a small circular shape in the top right corner, were retouched very carefully in many parallel, horizontal strokes.

Cross section of paint layer of Objeto ativo (amarelo) shows a bean-shaped paint sample with blobs of white on the bottom, topped by a very solid layer of yellow and then a yellow layer that looks less solid.

Paint cross section of Objeto ativo (amarelo), from top center edge of work, ca. 200x magnification. At the bottom is a white ground layer, followed by a homogenous yellow paint layer and above, at top, a more coarsely pigmented yellow paint layer.

To the naked eye, they are only barely visible in raking light due to a slightly higher gloss in these areas. The entire surface was then repainted with yellow oil paint (linseed oil mixed with pine resin), which, based on its yellowish fluorescence, has already oxidized to some degree, although the fluorescence might partially derive from the original white ground and paint layers underneath, which are also based on linseed oil (but with no pine resin added).

In order to better characterize the two yellow layers, a paint cross section was taken from the center top edge of the work.

The layers can be clearly distinguished because the lower, first paint layer above the white ground is homogeneous with only one yellow synthetic organic pigment present, Hansa Yellow (PY3), while the upper layer is more coarsely pigmented and also contains tiny blue particles. The yellow pigment in the upper layer is Arylide Yellow (PY4). The bright fluorescence of the blue band and square can be attributed to the presence of cobalt blue, which as mentioned above has a stimulating effect on the aging of linseed oil. The brightness of fluorescence in these areas is further enhanced by the fluorescence of the white ground underneath.(5)

Accepting Ambiguity

In Objeto plástico by Geraldo de Barros from 1952, the situation is somewhat more puzzling.

At left, image of Objeto plástico under visible light shows a somewhat star-like arrangement of red, dark yellow, and black shapes—some thin triangles, one square, one parallelogram, and one almost rectangle. The background is a light beige-gray. At right, the painting under UV shows the background as a grayish purple, the yellow shapes are a lighter lemon yellow, the black shapes look blue-green, and the red shapes light rust.

Left: Objeto plástico, 1952, Geraldo de Barros (Brazilian, 1923–98). Alkyd on wood, 36.8 × 45.1 × 2.4 cm. Colección Patricia Phelps de Cisneros. Right: Objeto plástico under UV illumination.

The red, ochre, and black shapes on top of a white background all fluoresce vibrantly in red, yellow, and green under UV. Some grey retouchings can also be seen dotted around the perimeter of the surface. The pigment class of cadmium pigments—available in shades of yellow, orange, and red—was frequently used by painters in the 1950s and is also known to exhibit fluorescence under UV. But because of their toxicity in powder form, cadmium pigments have been replaced over time with synthetic organic pigments. The three main classes of synthetic organic pigments used in artists’ paints today are quinacridone, azo, and phthalocyanine compounds, which also display strong UV fluorescence under certain conditions.(6)

Photomicrograph of the red shape in the center of Objeto plástico. The uppermost red paint layer sits on top of a white layer. Beneath the white layer a black paint layer can be seen in the paint cracks and along the edges of the form.

Photomicrograph of the red longitudinal shape in the center of Objeto plástico. The uppermost red paint layer sits on top of a white layer. Beneath the white layer a black paint layer can be seen in the paint cracks and along the edges of the form.

The pigments of this work have not yet been identified in detail, except for the red paint, which is a synthetic organic pigment. The most striking green fluorescence of the black pigment is less straightforward to understand. There are no black pigments, natural or synthetic, which are known to fluoresce.

Close examination with a microscope revealed that the shapes, all of which stand proud, were first painted in white, on top of the white background, followed by ochre, red, and black, however not in the current color scheme.

Presumably dissatisfied with the initial outcome, de Barros added another white layer over the entire surface to provide a “blank slate” for the final color scheme, in which only the ochre parallelogram in the bottom left quarter remained the same color. The red shapes and ochre vector were initially painted black, and the now-black shapes were initially red.

One of the underlying white layers, alkyd-based like the paint of the shapes, can be seen to strongly fluoresce underneath the edges of the uppermost colored layers, which very likely created interference with the surface layers. Based on the distribution of fluorescence in all of the shapes, my colleagues and I concluded that perhaps an additional dilute varnish layer was applied on top. This would also explain why the thinnest section of the black shape on the right does not fluoresce: the medium was not applied consistently.

Anomalies in Paint

At left, visible light of Cromática 6 shows a beigish-yellow rectangle bisected by a line that starts at the upper left corner, dips down to become a vertical line at center, and then dips down again to the right corner. The right side of the canvas is a darker shade of the color on the left. At right, the UV image of the painting renders as slightly different greens with darker splotches mostly in the middle of the canvas.

Left: Cromática 6, 1960, Aluísio Carvão (Brazilian, 1920–2001). Alkyd, drying oil, and beeswax on hardboard, 26.4 × 34 × 1.5 cm. Colección Patricia Phelps de Cisneros. Right: Cromática 6 under UV illumination.

The final object, a work by Aluísio Carvão called Cromática 6 from 1960, displays a very interesting anomaly under UV. As can be seen above, there are a few small areas with irregular contours typical for liquids being splashed onto an uneven surface and that fluoresce a bright yellow under UV.

Image shows cross section of paint from Cromática 6 that is black at bottom, at middle a jagged section that looks like yello sponge, and at top a gray like fogged window glass.

Paint cross section of Cromática 6, ca. 300x magnification, taken from the top left corner. Above a white ground layer, five ochre-colored paint layers can be seen, packed with colorless extenders such as gypsum and barium sulfate and contain only a few pigments, but with high tinting strength, such as zinc chromate, titanium white, as well as chrome yellow and an organic yellow pigment. The uppermost, extremely thin toning layer contains primarily titanium white and gypsum.

Scientific pigment analysis and cross sections show that the multiple paint layers are tightly packed with colorless extenders such as gypsum and barium sulfate and contain only a few pigments, but with high tinting strength, such as zinc chromate and titanium white, as well as chrome yellow and an organic yellow pigment.

The uppermost, extremely thin toning layer contains primarily titanium white and gypsum. In other words, with the exception of the tiny amounts of yellow organic pigment present underneath, the rest of the pigments cannot be considered contributors to the localized fluorescence. But the matte paint itself, which consists of alkyd, drying oil, and beeswax and was presumably mixed by Carvão himself, is heavily underbound, meaning there is very little paint medium present relative to the amount of pigments.

Because a hand-mixed paint is not as evenly dispersed as an industrially mixed paint, displacement and concentration of the oil components in the tide mark pattern indicative of a liquid state can happen more easily if, for example, a solvent is accidentally splashed onto the surface.

This speculation of how the tide marks might have been created is supported by the fact that these areas do not appear radically different from the surrounding paint surface under regular lighting conditions—in fact, only when one’s attention is drawn to them can these small areas be seen to be characterized by a slightly noticeable decrease in granularity, due to a temporary solubilization and redistribution of the paint matrix.

We will never know exactly what or when this incident happened, but thankfully it does not detract in any way from the enjoyment of this beautiful, subtly wrought composition.

The six examples discussed here present a variety of phenomena that only become visible to us by accessing the invisible parts of the electromagnetic spectrum. The resulting images greatly inform our understanding of the making and the history of a work of art, but their interpretation often requires the combined expertise of an entire group of conservation professionals.
