Small enough to hold in the hand, the allure of the Mira Calligraphiae Monumenta (Wondrous Monuments of Calligraphy) in the Getty Museum’s collection of manuscripts is undeniable. Hold the book close enough, and the butterflies seem to quiver before your eyes and the fruit looks good enough to eat.

Drawing of shell, two pears, and a butterfly around text written in tiny letters that swirl around to create a pattern

Butterfly, Marine Mollusk, and Pear, script by Georg Bocskay, dated 1561–1562; illuminations added by Joris Hoefnagel, 1591–1596. Watercolors, gold and silver paint, and ink on parchment, 6 9/16 × 4 7/8 in. The J. Paul Getty Museum, Ms. 20 (86.MV.527), fol. 118. Digital image courtesy of Getty’s Open Content Program

This manuscript contains a collection of models for elaborate and decorative script, written during the 1560s by calligrapher Georg Bocskay. Thirty years later artist Joris Hoefnagel filled the available blank spaces with exquisitely-painted naturalistic depictions of flowers, fruits, seedpods, insects, caterpillars, mollusks, lizards, frogs, mice, and other small creatures. The detail is so fine, his brushstrokes are nearly invisible to the naked eye.

Hoefnagel’s contributions completely transformed the book. His images create a unique experience, placing nature’s cornucopia in the reader’s hand, and inspiring awe and wonder in the late-16th-century viewer.

Fast forward to 2020, and the digital age. Now, new imaging has captured the subtle hues of Hoefnagel’s pigments and colorants, as well as the color and surface texture of the parchment.

A paragraph of text written in all caps in bold calligraphy and under the text are drawings of a pink tulip and multicolored tulip with their stems intertwined, and a black and white kidney bean and a brown round bean

Gesner’s Tulip, Ichneumon Fly, Kidney Bean, and Scarlet Runner Bean, script by Georg Bocskay, dated 1561–1562; illuminations added by Joris Hoefnagel, 1591–1596. Watercolors, gold and silver paint, and ink on parchment, 6 9/16 × 4 7/8 in. The J. Paul Getty Museum, Ms. 20 (86.MV.527), fol. 23. Digital image courtesy of Getty’s Open Content Program

Viewable in a newly published facsimile and online, readers can now appreciate the impossibly tiny spiraling micro-writing; observe the subtle differences between the green leaves of the crossed tulips; almost feel the rusting surface of the apple; and be delighted by the hair-fine web spun by the spider. Each page of the new book reflects the quantum leaps in digital technologies since the 1992 publication of Getty’s first facsimile edition.

Two paragraphs of text written in calligraphy, surrounded by an intricate frame of floral vines and curled pattern. Below the frame is a drawing of two pink roses and an apple cut in half to reveal the seeds

French Rose and Apple, script by Georg Bocskay, dated 1561–1562; illuminations added by Joris Hoefnagel, 1591–1596. Watercolors, gold and silver paint, and ink on parchment, 6 9/16 × 4 7/8 in. The J. Paul Getty Museum, Ms. 20 (86.MV.527), fol. 107. Digital image courtesy of Getty’s Open Content Program

Paragraph of text written in calligraphy and below the paragraph are drawings of a pink rose and its stem, a spider, a dragonfly-like insect, and a chestnut

Damselfly, French Rose, Spanish Chestnut, and Spider, script by Georg Bocskay, dated 1561–1562; illuminations added by Joris Hoefnagel, 1591–1596. Watercolors, gold and silver paint, and ink on parchment, 6 9/16 × 4 7/8 in. The J. Paul Getty Museum, Ms. 20 (86.MV.527), fol. 10. Digital image courtesy of Getty’s Open Content Program

Along with the new images, recent advances in methods of scientific analysis brought to light information about how Hoefnagel painted these astonishingly lifelike depictions. Non-invasive systems that do not touch or remove anything from the surface of the page provided clues to the pigments he used in almost every brushstroke. One of these techniques, macro X-ray fluorescence (MA-XRF) scanning, used a narrow beam of X-rays to map the distribution of chemical elements (e.g. lead, iron, copper) across the surface of the page. Knowing these elements made it possible to identify which pigments were used.

Photo of a page from a manuscript decorated with drawings of an apple, flowers and a snail, under a lamp and a tool featuring a pen-like tip

The macro X-ray fluorescence (XRF) spectrometer in position to record the distribution of chemical elements across the painted image of the sour orange. Note that the tip of the instrument is several millimeters away from the surface of the page, ensuring that the manuscript is not damaged in any way.

Hoefnagel’s extraordinary illusionistic effects may seem like they’d depend on a whole new range of materials. But his paints were found to be no different than those of generations of manuscript illuminators who came before him. It was how he used them that sets him apart.

Attuned to the slightly different hues, textures, and opacities achievable by his materials, Hoefnagel carefully selected each pigment to achieve the desired effect. For example, the sour orange was painted with several different red and yellow pigments, including orpiment yellow, vermilion red, red lead, and red ochre.

A paragraph of text with swirled calligraphy lines and designs above and below the text, and drawings of half an orange, a brown mollusk, and two purple flowers

Sour Orange, Terrestrial Mollusk, and Larkspur, script by Georg Bocskay, dated 1561–1562; illuminations added by Joris Hoefnagel, 1591–1596. Watercolors, gold and silver paint, and ink on parchment, 6 9/16 × 4 7/8 in. The J. Paul Getty Museum, Ms. 20 (86.MV.527), fol. 33. Digital image courtesy of Getty’s Open Content Program

Four pictures arranged in a grid: in the top left, a painting of half a lemon, in the top right, a black and white image of the lemon with the interior fruit bright white labeled lead; in the bottom left, a black and white image of the lemon outlined evenly in white with the label iron; in the bottom right, a black and white image of the lemon with the skin more deeply outlined in white with the label arsenic

Maps showing the distribution of elements in a detail of the sour orange. The individual dots along the edge of the rind and the lines outlining the pips are less than half a millimeter wide, highlighting the tremendous skill Hoefnagel had for creating highly detailed illustrations.

The element maps produced by the macro-XRF scanner shed light on how Hoefnagel mixed and layered his pigments. For this sour orange, the artist combined the mineral pigment orpiment yellow (seen in the arsenic map above) together with red and yellow earth pigments (captured in the map for iron, above) to create the rind. He used lead-containing pigments (either white lead and/or red lead, shown in the map for lead, above) to create the distinctive outlines of the fruit’s individual sections and seeds. Although this imaging technique cannot detect organic pigments, it looks like he used an organic yellow pigment on the white inner rind, to differentiate it from the white of the parchment.

Throughout the book, Hoefnagel selected different red and yellow pigments, exploiting each pigment’s unique quality for a particular purpose. For example, to paint a dragonfly, he used the cool yellow hue of the pigment lead-tin yellow to articulate its sectioned body. He also used an insect-derived lake pigment (possibly cochineal) for the bright magenta leaves of the carnation.

Paragraph of text written in calligraphy, with paintings of a dragonfly, pear, pink carnation, and an insect with wings underneath

Dragonfly, Pear, Carnation, and Insect, script by Georg Bocskay, dated 1561–1562; illuminations added by Joris Hoefnagel, 1591–1596. Watercolors, gold and silver paint, and ink on parchment, 6 9/16 × 4 7/8 in. The J. Paul Getty Museum, Ms. 20 (86.MV.527), fol. 76. Digital image courtesy of Getty’s Open Content Program

Close-up view of painting of a dragonfly, with part of its body, head, and wings visible

Microscope detail image showing lead tin yellow (type I) used to articulate the dragonfly’s body

Because it uses X-rays, macro-XRF scanning can also see below the surface of the paint.  Surprisingly, on one page, words hidden beneath the flower vase in the page margin at right could be seen in the lead map. What do they say? We don’t know. Yet.

Pic 1: An book opened to a page with colorful drawings and calligraphy scrolls, with two hands placing a piece of paper behind the page. Pic 2: Close-up view of a brown and gold vase with flowers spilling out the top. Pic 3: a black and white version of the same image that shows two words appearing in white on top of the vase

Left: A sheet of protective material is placed under the page to be studied to minimize elements in underlying pages being detected. Center and right: Detail of the vase, and the mysterious words hidden under the surface paint layer but revealed in the map of lead

Even if we can’t read it, this discovery may hold a clue to the creative process. Was this text something Bocskay made as a test, that Hoefnagel cleverly hid beneath the vase? With intriguing discoveries like these, entirely new questions emerge. New findings help direct future research. This manuscript will continue to fascinate all those who encounter it—now and into the future—as new technologies become available that will further reveal its wonders.

You can buy a copy of the new facsimile at the Getty Store.
